LC1G185KUEN

Introducing the AEC Switchgear  TeSys Giga high power contactor LC1G185KUEN designed for AC-3 applications up to 185A 110kW@440V. This powerhouse features a wide band low consumption electronic coil and 1NO+1NC auxiliary contact block for maximum reliability. With a mechanical durability of 5 Mcycles and operating rates up to 600 cycles per hour, this contactor is built to last in demanding environments up to 60°C.(LC1G185KUEN)

The innovative Local Contact Wear Diagnosis (CWD) function allows for continuous monitoring, ensuring long-lasting performance. Maintenance is a breeze with the ability to replace the switching module without removing cables or busbars. Plus, the contactor can be fixed in all quadrants and OLR can be mounted directly below for convenience.

With IP2x protection and shrouds conforming to IEC 60529 and VDE 0106, this contactor is built to withstand the elements. From -25°C to 60°C operation ambient air temperature and no derating up to 3000m altitude, this contactor is ready for anything.
